Flow Range: 0.01～100.00 mL/min for IPC-50 system;

1～500 mL/min for IPC-100 system;

1～1000 mL/min for IPC-150 system;

Max working pressure: 30 MPa for IPC-50 system;

20 MPa for IPC-100 system;

20 MPa (at 1-500 mL/min), and 10 MPa (at 501-1000 mL/min ) for IPC-150 system;

UV-Vis Dector Wavelength range: 190 nm ~ 700 nm

IPC-50 system: The Elite IPC-50 IPC System consists of two P3700 high-pressure pumps, an online UV3100 detector, an Elite DAC-50 dynamic axial compression column, and a high-pressure 6-way injection valve or feed pump. Designed for gram-scale preparation, it is suitable for lab to semi-preparative applications and process scale-up studies, offering ease of use and low operating cost.

IPC-100 System: comprises two P500+ high-pressure constant-flow pumps, an online UV3100 detector, an Elite DAC-100 dynamic axial compression column, and a high-pressure 6-way injection valve or feed pump. Designed as a robust and cost-effective preparative HPLC system, it meets the separation and purification needs of small R&D teams, enabling gram-scale sample preparation. It is particularly suitable for emerging traditional Chinese medicine research groups.

IPC-150 System: integrates two P1000+ high-pressure constant-flow pumps, an online UV3100 detector, an Elite DAC-150 dynamic axial compression column, and a high-pressure 6-way injection valve or feed pump. Designed for large purification laboratories, this automated and cost-effective preparative HPLC system supports sample preparation up to 10 grams, making it a suitable choice for high-throughput purification needs.

The IPC series industrial preparative chromatography system offers the following components, which can be selected according to your needs:
