D3210 UV-Vis Detector

The D3210 UV-Visible Detector supports four operational modes—single wavelength, dual wavelength, spectrum scanning, and time-wavelength program—offering exceptional flexibility for various analytical applications. Equipped with both deuterium and tungsten lamps, it enables seamless detection from the ultraviolet to the visible light range. The instrument incorporates a high-precision, self-calibrating analog-to-digital converter and an advanced optical path system, ensuring excellent wavelength accuracy, repeatability, and signal-to-noise performance. The motor-driven grating mechanism provides precise wavelength positioning and high linearity across the full wavelength range. Intelligent features include automatic power-on self-test, leak alarm, automatic wavelength calibration, and real-time monitoring of lamp usage time and ignition count via the workstation. Simultaneous digital and analog signal output enhances system integration and data handling flexibility.

Operation-Manual-for-D3210-UV-VIS-Detector.pdf

Specifications

Optical System: Dual wavelength

Light Sources: Deuterium lamp (UV), Tungsten lamp (Vis)

Wavelength Range: 190 – 800 nm

Maximum Backpressure on Flow Cell: 1000 psi

Communication Interface: UDP (Ethernet)

Dimensions (W × D × H): 440 mm × 380 mm × 160 mm

Weight: 10 kg

Power Requirements: AC 220 V ± 10%, 50/60 Hz

Power Consumption: 100 W

Performance

The D3210 UV-Visible Detector is designed for high-performance liquid chromatography (HPLC) systems, delivering reliable and sensitive detection in single or dual wavelength mode, full-spectrum scanning, and automated wavelength switching via time-programmed methods. Its low noise, high linearity, and selectable sampling rates ensure accurate quantification for both routine and complex analyses. Fully controllable through the W5100 chromatography workstation via UDP communication, the detector supports seamless integration into modular HPLC systems, making it ideal for pharmaceutical, biomedical, environmental, and quality control laboratories.
