Supersil GOLD packings based on silica gel with a particle size of 3μm, 5μm and 10μm and a pore size of 120Å. The quality control standards of the production process are very strict.
| StationaryPhase | Particle Size(μm) | Specific Surface Area(m2/g) | Pore Size(Å) | Carbon Content(C%) | End-capping |
|---|---|---|---|---|---|
| Supersil Gold NH2/NH2-S | 5 | 170 | 120 | 1.9 | Y |
| Stationary Phase | Particle Size (μm) | Size (mm) | P/N |
|---|---|---|---|
| Supersil Gold NH2 | 5 | 4.6×150 | 3111-n2155-051-C |
| 5 | 4.6×200 | 3111-n2155-061-C | |
| 5 | 4.6×250 | 3111-n2155-071-C | |
| 5 | 4.6×300 | 3111-n2155-081-C | |
| 10 | 4.6×150 | 3111-n2165-051-C | |
| 10 | 4.6×200 | 3111-n2165-061-C | |
| 10 | 4.6×250 | 3111-n2165-071-C | |
| 10 | 4.6×300 | 3111-n2165-081-C |
| Stationary Phase | Particle Size (μm) | Size (mm) | P/N |
|---|---|---|---|
| Supersil Gold NH2-S | 5 | 4.6×150 | 3111-n4255-051-C |
| 5 | 4.6×200 | 3111-n4255-061-C | |
| 5 | 4.6×250 | 3111-n4255-071-C | |
| 5 | 4.6×300 | 3111-n4255-081-C |
*For column specifications not mentioned, please contact us for further information.
